PermutationImportanceDisplay#

class skore.PermutationImportanceDisplay(*, importances, report_type)[source]#

Display permutation feature importances.

Parameters:
importancespd.DataFrame

The importances computed after permuting the input features. The columns are:

  • estimator

  • data_source

  • metric

  • split

  • feature

  • label or output (classification vs. regression)

  • repetition

  • value

report_type{“estimator”, “cross-validation”, “comparison-estimator”, “comparison-cross-validation”}

Report type from which the display is created.

Attributes:
importancespd.DataFrame

Permutation importance values per feature, metric, and repetition.

report_typeReportType

The type of report.

See also

EstimatorReport.inspection.permutation_importance

Create this display.

CoefficientsDisplay

Display linear model coefficients.

ImpurityDecreaseDisplay

Display tree-based MDI importances.

Notes

For cross-validation and comparison reports, frame() and plot() can aggregate importances across splits using the aggregate parameter.

frame(*, metric=None, aggregate=('mean', 'std'), level='splits', select_k=None, sorting_order=None)[source]#

Get the feature importance in a dataframe format.

Parameters:
metricstr or list of str, default=None

Filter the importances by metric. If None, all importances associated with each metric are returned.

aggregate{“mean”, “std”}, (“mean”, “std”) or None, default=(“mean”, “std”)

How to aggregate the importances. Applied on repetitions or on repetitions then splits, for (comparisons of) cross validation reports and depending on the value of level.

level{“splits”, “repetitions”}, default=”splits”

Over which dimensions to aggregate when aggregate is not None. "repetitions" aggregates only over repetitions (keeps split for cross-validation). "splits" aggregates over repetitions then over splits. Only relevant when aggregate is not None and the report is a CrossValidationReport or a ComparisonReport containing such type of report.

select_kint, default=None

Select features by importance:

  • Positive values: the select_k features with largest importance

  • Negative values: the -select_k features with smallest importance

Selection is performed independently within each group (estimator, and per label/output if applicable). For cross-validation, features are ranked by mean importance across splits. When aggregate is None, ranking uses mean importance per feature over repetitions (and splits); all repetition/split rows are kept for the selected features.

sorting_order{“descending”, “ascending”, None}, default=None

Sort features by importance: “descending” (most important first), “ascending” (least important first), or None to preserve original order. Can be used independently of select_k. When aggregate is None, ordering uses mean importance per feature over repetitions (and splits).

Returns:
pd.DataFrame

The feature importances. The columns depend on the report type and parameters, and include:

  • data_source: Data source used to compute the importances ("train" or "test").

  • metric: Metric used to compute the importances.

  • feature: Feature name.

  • value_mean and value_std: Aggregated importance values (only when aggregate is not None).

  • value: Raw importance value per repetition (only when aggregate is None).

  • estimator: Name of the estimator (for comparison reports).

  • split: Cross-validation split index (for cross-validation reports, only when aggregate is None).

  • label: Class label (for multiclass classification).

  • output: Output index (for multi-output regression).

help()[source]#

Display display help using rich or HTML.

plot(*, metric=None, subplot_by='auto', select_k=None, sorting_order=None)[source]#

Plot the permutation importance.

Parameters:
metricstr or None, default=None

Metric to plot. Required when multiple metrics are computed.

subplot_bystr or None, default=”auto”

Column to use for subplotting. The possible values are:

  • if "auto", depending of the information available, a meaningful decision is made to create subplots.

  • if a string, the corresponding column of the dataframe is used to create several subplots. Those plots will be organized in a grid of a single row and several columns.

  • if None, all information is plotted on a single plot. An error is raised if there is too much information to plot on a single plot.

select_kint, default=None

If set, only the top (positive) or bottom (negative) k features by importance are shown. See frame() for details.

sorting_order{“descending”, “ascending”, None}, default=None

Sort features by importance before plotting. See frame() for details.

Returns:
matplotlib.figure.Figure

Figure containing the permutation importance plot.

set_style(*, policy='update', boxplot_kwargs=None, stripplot_kwargs=None)[source]#

Set the style parameters for the display.

Parameters:
policy{“override”, “update”}, default=”update”

Policy to use when setting the style parameters. If “override”, each provided group replaces the previous value. Omitted groups are left unchanged. If “update”, merge provided values into the existing settings. Passed keys replace the previous value. Nested dictionaries are merged the same way, so omitted keys are kept.

boxplot_kwargsdict, default=None

Keyword arguments to be passed to seaborn.boxplot() for rendering the importances with a EstimatorReport.

stripplot_kwargsdict, default=None

Keyword arguments to be passed to seaborn.stripplot() for rendering the importances with a EstimatorReport.

Returns:
None
Raises:
ValueError

If a style parameter is unknown.

static style_plot(plot_func)[source]#

Apply consistent style to skore displays.

This decorator: 1. Applies default style settings 2. Runs plot_func under plt.ioff() so figures are not shown until returned 3. Calls Figure.tight_layout() on the returned figure when applicable 4. Restores the original style settings

Parameters:
plot_funccallable

The plot function to be decorated.

Returns:
callable

The decorated plot function.
